LUXBEAM B40
The LUXBEAM B40 Dual-Color LED Spotlight – Red Dot Award Winner 2024 – sets a new benchmark in professional lighting. Recognized globally for outstanding design, this award-winning spotlight delivers a perfectly uniform light spectrum with precise dual-color temperature control, making it ideal for studios, film sets, and stage environments.
Engineered with advanced heat dissipation, an innovative optical system, and premium LED light sources, the LUXBEAM B40 combines powerful illumination with low energy consumption. For maximum convenience, it features a quick-adjust center of gravity and a detachable bracket for fast, flexible installation.
Crafted from high-quality stainless steel, every detail reflects durability, reliability, and a premium finish. With its award-winning design and professional-grade performance, the LUXBEAM B40 LED Spotlight is the perfect choice for creators who demand both style and precision.
Power
Input Voltage: AC 100-240 V
Power Consumption: 1200 W
Output
Color Temperature (CCT): 2700 K – 10000 K (continuously adjustable)
Dimming Range: 0 % – 100 %
LED Type / Mode: Bi-color LED
CRI: > 95
TLCI: > 90
Beam / Zoom Lens Angle: 10° – 45° (zoomable)
CRI≥ 95
2700-10000K
Beam angle 9º-45°
Adjusting the centre of gravity
Modular lighting frame
IP65 Waterproof Rating
Control & Connectivity
DMX Control: DMX-512 via 5-pin XLR (In / Out)
Wireless Control: LumenRadio (CRMX / W-DMX)
App Control: iOS / Android
General
Mount Type: 28 mm stud
Weight (Light Head): ~ 8.2 kg
Weight (Yoke): ~ 1.5 kg
Dimensions (Light Head): 340 × 222 × 190 mm
IP Rating: IP65 (weatherproof)
Photometric Data
Light Head (60°)
| Distance | 3m | 5m | 7m | 9m |
|---|---|---|---|---|
| Illuminance (fc) 3200K | 832 | 299 | 152 | 92 |
| Illuminance (fc) 5600K | 995 | 358 | 182 | 110 |
| Beam Diameter (ft) | 13.8 | 22.9 | 32.2 | 41.3 |
Auto Fresnel Lens (10°)
| Distance | 3m | 5m | 7m | 9m |
|---|---|---|---|---|
| Illuminance (fc) 3200K | 11116 | 4002 | 2042 | 1235 |
| Illuminance (fc) 5600K | 13192 | 4749 | 2423 | 1467 |
| Beam Diameter (ft) | 2.4 | 3.9 | 5.5 | 7.1 |
Auto Fresnel Lens (45°)
| Distance | 3m | 5m | 7m | 9m |
|---|---|---|---|---|
| Illuminance (fc) 3200K | 1255 | 452 | 230 | 140 |
| Illuminance (fc) 5600K | 1480 | 532 | 272 | 165 |
| Beam Diameter (ft) | 8.2 | 13.5 | 19 | 24.6 |
