Evoke 5C Nanlux

Evoke 5C

Technical Data

Rated Power: 6W
Input Voltage: DC5V/2A

Beam Angle: 25°
LED Light Engine: Nebula C8 Light Engine (dRRALGCBI)
CCT: 1000K – 20000K (G/M ±200)
CRI: Average 98
TLCI: Average 98
TM-30 Rf: Average 96
TM-30 Rg: Average 100
Dimming: 0.0% – 100.0%, adjustable in 0.1% increments

Product Size

Light Fixture: 56×44×45mm/2.2×1.73×1.77″

USB-C Cable: 1m/39.37″

AS-MD-EV5C Magnetic Diffuser: 44×44×11mm/1.73×1.73×0.433″

YK-EV5C Magnetic Yoke: 67×42×69mm/2.64×1.65×2.72″

AS-MTS-EV5C Magnetic Thermal Shield: 48×48×31mm/1.89×1.89×1.22″

Standard Kit Carrying Bag: 135×50×75mm/5.31×1.97×2.95″

Evoke 5C KIT Carrying Bag: 190×60×100mm/7.48×2.36×3.94″

Product Weight

Light Fixture: 160g/0.353lb

USB-C Cable: 28g/0.0617lb

AS-MD-EV5C Magnetic Diffuser: 8g/0.0176lb

YK-EV5C Magnetic Yoke: 62g/0.137lb

AS-MTS-EV5C Magnetic Thermal Shield: 9g/0.0198lb

Standard Kit Carrying Bag: 76g/0.168lb

Evoke 5C KIT Carrying Bag: 168.2g/0.371lb

Illumination (Lux / Fc)

Configuration	Distance	2700K	3200K	5600K	6500K	R	G	B
Light Only	0.3M	4950 lux / 460 fc	5480 lux / 509 fc	5970 lux / 555 fc	6190 lux / 575 fc	929 lux / 86 fc	8080 lux / 751 fc	1174 lux / 109 fc
Light Only	0.5M	1660 lux / 154 fc	1835 lux / 170 fc	2026 lux / 188 fc	2089 lux / 194 fc	308 lux / 29 fc	2755 lux / 256 fc	404 lux / 38 fc
Light Only	1M	404 lux / 38 fc	448 lux / 42 fc	496 lux / 46 fc	511 lux / 47 fc	73 lux / 3 fc	671 lux / 62 fc	99 lux / 9 fc
Evoke 5C Magnetic Fresnel Lens (25°)	0.3M	11340 lux / 1054 fc	12570 lux / 1168 fc	13830 lux / 1285 fc	14360 lux / 1334 fc	2120 lux / 197 fc	18800 lux / 1747 fc	2720 lux / 253 fc
Evoke 5C Magnetic Fresnel Lens (25°)	0.5M	3270 lux / 304 fc	3630 lux / 337 fc	4020 lux / 374 fc	4160 lux / 387 fc	595 lux / 55 fc	5390 lux / 501 fc	779 lux / 72 fc
Evoke 5C Magnetic Fresnel Lens (25°)	1M	678 lux / 63 fc	750 lux / 70 fc	830 lux / 77 fc	856 lux / 80 fc	123 lux / 11 fc	1127 lux / 105 fc	164 lux / 15 fc
Evoke 5C Magnetic Fresnel Lens (35°)	0.3M	6320 lux / 587 fc	7010 lux / 651 fc	7860 lux / 730 fc	8130 lux / 755 fc	1170 lux / 109 fc	10410 lux / 967 fc	1511 lux / 140 fc
Evoke 5C Magnetic Fresnel Lens (35°)	0.5M	2076 lux / 193 fc	2296 lux / 213 fc	2533 lux / 235 fc	2629 lux / 244 fc	385 lux / 36 fc	3450 lux / 321 fc	505 lux / 47 fc
Evoke 5C Magnetic Fresnel Lens (35°)	1M	470 lux / 44 fc	518 lux / 48 fc	580 lux / 54 fc	597 lux / 56 fc	86 lux / 8 fc	796 lux / 74 fc	114 lux / 11 fc
Evoke 5C Magnetic Spot Beam Lens	0.5M	8760 lux / 814 fc	9710 lux / 902 fc	10770 lux / 1001 fc	11100 lux / 1031 fc	1622 lux / 151 fc	14910 lux / 1385 fc	2176 lux / 202 fc
Evoke 5C Magnetic Spot Beam Lens	1M	2305 lux / 214 fc	2548 lux / 237 fc	2828 lux / 263 fc	2930 lux / 272 fc	416 lux / 39 fc	3870 lux / 360 fc	557 lux / 52 fc
Evoke 5C Magnetic Spot Beam Lens	2M	554 lux / 52 fc	604 lux / 56 fc	677 lux / 63 fc	702 lux / 65 fc	100 lux / 9 fc	928 lux / 86 fc	132 lux / 12 fc
Evoke 5C Projection Attachment 15°-35° (15°)	0.5M	2772 lux / 258 fc	3050 lux / 283 fc	3380 lux / 314 fc	3530 lux / 328 fc	515 lux / 48 fc	4610 lux / 428 fc	682 lux / 63 fc
Evoke 5C Projection Attachment 15°-35° (15°)	1M	593 lux / 55 fc	656 lux / 61 fc	726 lux / 67 fc	753 lux / 70 fc	111 lux / 10 fc	974 lux / 91 fc	145 lux / 14 fc
Evoke 5C Projection Attachment 15°-35° (15°)	2M	143 lux / 13 fc	157 lux / 15 fc	173 lux / 16 fc	180 lux / 17 fc	26 lux / 2 fc	234 lux / 22 fc	34 lux / 3 fc
Evoke 5C Projection Attachment 15°-35° (35°)	0.5M	1044 lux / 97 fc	1156 lux / 107 fc	1278 lux / 119 fc	1326 lux / 123 fc	195 lux / 18 fc	1724 lux / 160 fc	255 lux / 24 fc
Evoke 5C Projection Attachment 15°-35° (35°)	1M	188 lux / 18 fc	207 lux / 19 fc	229 lux / 21 fc	238 lux / 22 fc	35 lux / 3 fc	312 lux / 29 fc	46 lux / 4 fc
Evoke 5C Projection Attachment 15°-35° (35°)	2M	40 lux / 4 fc	45 lux / 4 fc	49 lux / 5 fc	51 lux / 5 fc	7 lux / 1 fc	67 lux / 6 fc	9 lux / 1 fc
Evoke 5C Magnetic Snoot	0.3M	863 lux / 80 fc	955 lux / 89 fc	1050 lux / 98 fc	1094 lux / 102 fc	163 lux / 15 fc	1427 lux / 133 fc	205 lux / 19 fc
Evoke 5C Magnetic Snoot	0.5M	233 lux / 22 fc	261 lux / 24 fc	287 lux / 27 fc	300 lux / 28 fc	44 lux / 4 fc	391 lux / 36 fc	56 lux / 5 fc
Evoke 5C Magnetic Snoot	1M	50 lux / 5 fc	55 lux / 5 fc	61 lux / 6 fc	64 lux / 6 fc	9 lux / 1 fc	83 lux / 8 fc	12 lux / 1 fc
Evoke 5C Magnetic Diffuser	0.3M	251 lux / 23 fc	277 lux / 26 fc	303 lux / 28 fc	316 lux / 29 fc	48 lux / 5 fc	411 lux / 38 fc	59 lux / 6 fc
Evoke 5C Magnetic Diffuser	0.5M	80 lux / 7 fc	89 lux / 8 fc	97 lux / 9 fc	101 lux / 9 fc	15 lux / 1 fc	131 lux / 12 fc	18 lux / 2 fc
Evoke 5C Magnetic Diffuser	1M	19 lux / 2 fc	21 lux / 2 fc	23 lux / 2 fc	24 lux / 2 fc	3 lux / 0.3 fc	31 lux / 3 fc	4 lux / 0.4 fc
Evoke 5C Magnetic Soft Dome	0.3M	199 lux / 19 fc	220 lux / 20 fc	242 lux / 23 fc	251 lux / 23 fc	37 lux / 3 fc	327 lux / 30 fc	48 lux / 5 fc
Evoke 5C Magnetic Soft Dome	0.5M	61 lux / 6 fc	67 lux / 6 fc	74 lux / 7 fc	77 lux / 7 fc	11 lux / 1 fc	101 lux / 9 fc	14 lux / 1 fc
Evoke 5C Magnetic Soft Dome	1M	14 lux / 1 fc	15 lux / 1 fc	17 lux / 2 fc	17 lux / 2 fc	2 lux / 0.2 fc	23 lux / 2 fc	3 lux / 0.3 fc
